PRODUCT SPECIFICATIONS
| MODEL | 3000 MAX | ||
|---|---|---|---|
| Oil Pressure Range | 80 – 240 Bar | ||
| Torque Range | 959 – 2877 Nm | ||
| Oil Flow Range | 27 – 75 lpm | ||
| Speed Range | 36 – 100 rpm | ||
| Hub Options | 65mm Round | ||
| Height | 665 mm | ||
| Width | 244 mm | ||
| Weight | 71 kg | ||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
||
| Auger Range | S4 | ||
| Rec. Drilling Diameter Range | 100 – 600 mm |
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the 3000-4500 series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading life-time warranty.
Please have a look at the below table for more specifications.
PRODUCT SPECIFICATIONS
| MODEL | 3000 MAX | ||
|---|---|---|---|
| Oil Pressure Range | 80 – 240 Bar | ||
| Torque Range | 959 – 2877 Nm | ||
| Oil Flow Range | 27 – 75 lpm | ||
| Speed Range | 36 – 100 rpm | ||
| Hub Options | 65mm Round | ||
| Height | 665 mm | ||
| Width | 244 mm | ||
| Weight | 71 kg | ||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
||
| Auger Range | S4 | ||
| Rec. Drilling Diameter Range | 100 – 600 mm |
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the 3000-4500 series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading life-time warranty.
Please have a look at the below table for more specifications.
Product Specification
| MODEL | 3500 MAX | ||
|---|---|---|---|
| Oil Pressure Range | 80 – 240 Bar | ||
| Torque Range | 1205 -3614 Nm | ||
| Oil Flow Range | 40 – 85 lpm | ||
| Speed Range | 42 – 90 rpm | ||
| Hub Options | 65mm Round | ||
| Height | 665 mm | ||
| Width | 244 mm | ||
| Weight | 73 kg | ||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
||
| Auger Range | S4 | ||
| Rec. Drilling Diameter Range | 100 – 750 mm |
PRODUCT RANGE
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the 3000-4500 series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading life-time warranty.
Please have a look at the below table for more specifications.
| MODEL | 4500 MAX | ||
|---|---|---|---|
| Oil Pressure Range | 80 – 240 Bar | ||
| Torque Range | 1500 – 4499 Nm | ||
| Oil Flow Range | 50 – 95 lpm | ||
| Speed Range | 43 – 81 rpm | ||
| Hub Options | 65mm Round | ||
| 665 mm | |||
| Width | 244 mm | ||
| Weight | 75 kg | ||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
||
| Auger Range | S4 | ||
| Rec. Drilling Diameter Range | 100 – 900 mm |
PRODUCT RANGE
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the 3000-4500 series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading life-time warranty.
Please have a look at the below table for more specifications.
| MODEL | 5500MAX | ||
|---|---|---|---|
| Oil Pressure Range | 80 – 260 Bar | ||
| Torque Range | 1685 – 5477 Nm | ||
| Oil Flow Range | 40 – 115 lpm | ||
| Speed Range | 30 – 87 rpm | ||
| Hub Options | 75mm Square | ||
| Height | 780 mm | ||
| Width | 269 mm | ||
| Weight | 108 kg | ||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
||
| Auger Range | S5 | ||
| Rec. Drilling Diameter Range | 150 – 750 mm |
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the 5500MAX-8000MAX series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
The Auger Torque 2-Way Valve is an optional extra on this series of Earth Drills and will enable you to convert a single acting hammer circuit into 2-way auxiliary flow.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading life time warranty.
Please have a look at the below table for more specifications.
| MODEL | 7000 MAX | ||
|---|---|---|---|
| Oil Pressure Range | 80 – 260 Bar | ||
| Torque Range | 2133 – 6931 Nm | ||
| Oil Flow Range | 60 – 135 lpm | ||
| Speed Range | 36 – 81 rpm | ||
| Hub Options | 75mm Square | ||
| Height | 780 mm | ||
| 269 mm | |||
| Weight | 112 kg | ||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
||
| Auger Range | S5 | ||
| Rec. Drilling Diameter Range | 150 – 900 mm |
PRODUCT RANGE
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the 5500MAX-8000MAX series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
The Auger Torque 2-Way Valve is an optional extra on this series of Earth Drills and will enable you to convert a single acting hammer circuit into 2-way auxiliary flow.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading life time warranty.
Please have a look at the below table for more specifications.
| MODEL | 8000 MAX | ||
|---|---|---|---|
| Oil Pressure Range | 80 – 240 Bar | ||
| Torque Range | 2717 – 8152 Nm | ||
| Oil Flow Range | 70 – 150 lpm | ||
| Speed Range | 33 – 70 rpm | ||
| Hub Options | 75mm Square | ||
| Height | 780 mm | ||
| Width | 269 mm | ||
| Weight | 116 kg | ||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
||
| Auger Range | S5 | ||
| Rec. Drilling Diameter Range | 150 – 1200 mm |
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the 5500MAX-8000MAX series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
The Auger Torque 2-Way Valve is an optional extra on this series of Earth Drills and will enable you to convert a single acting hammer circuit into 2-way auxiliary flow.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading life time warranty.
Please have a look at the below table for more specifications.
| MODEL | X2000 | |||
|---|---|---|---|---|
| Oil Pressure Range | 70 – 240 Bar | |||
| Torque Range | 639 – 2190 Nm | |||
| Oil Flow Range | 25 – 57 lpm | |||
| Speed Range | 43 – 99 rpm | |||
| Hub Options | 65mm Round | |||
| Height | 585 mm | |||
| Width | 200 mm | |||
| 47 kg | ||||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
|||
| Auger Range | S4 | |||
| Rec. Drilling Diameter Range | 100 – 450 mm |
PRODUCT RANGE
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the X1500-X2500 series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading warranty. Click here to find out more about our Lifetime Warranty and to register your product online.
Please have a look at the below table for more specifications.
| MODEL | X2500 | |||
|---|---|---|---|---|
| Oil Pressure Range | 70 – 240 Bar | |||
| Torque Range | 830 – 2847 Nm | |||
| Oil Flow Range | 27 – 65 lpm | |||
| Speed Range | 36 – 87 rpm | |||
| Hub Options | 65mm Round | |||
| Height | 585 mm | |||
| Width | 200 mm | |||
| Weight | 48 kg | |||
| Hitch Options | Single Pin Hitch Double Pin Hitch Cradle Hitch |
|||
| Auger Range | S4 | |||
| Rec. Drilling Diameter Range | 100 – 500 mm |
High quality hydraulic motors, output shaft bearings which are 50% larger than our nearest competitors comparable drive and the use of only high grade materials mean that your Earth Drill will have a long, reliable service life.
Standard with the X1500-X2500 series and unique to Auger Torque, the Non-Dislodgement Shaft is a single piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers. This is a MUST-HAVE FEATURE for any safety conscious company.
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.
High quality hoses and couplers are standard with this series of Earth Drills, type and size need to be specified at the time of purchase, rest assured we keep all standards in stock and you will be ready to use your Earth Drill the moment you take delivery.
All Earth Drills are covered by Auger Torque’s industry leading warranty. Click here to find out more about our Lifetime Warranty and to register your product online.
Please have a look at the below table for more specifications.
Augertorque Double Pin Cradle Hitch available for Earth Drills 10000 TO 15000Max in various Pin diameters (44mm(1/3/4″), 45mm, 50mm, 55mm, 60mm, 65mm, 70mm, 75mm, 80mm).
| 44mm DOUBLE PIN CRADLE HITCH – 10000Max TO 15000Max |
| 45mm DOUBLE PIN CRADLE HITCH – 10000Max TO 15000Max |
| 50mm DOUBLE PIN CRADLE HITCH – 10000Max TO 15000Max |
| 55mm DOUBLE PIN CRADLE HITCH – 10000Max TO 15000Max |
| 60mm DOUBLE PIN CRADLE HITCH – 10000Max TO 15000Max
65mm (1.3/4″) DOUBLE PIN CRADLE HITCH – 10000Max TO 15000Max |
The Double Pin Cradle Earth Drill hitch can be supplied in both loose and fixed pin versions to suit standard and quick hitch solutions on most excavators & backhoes. This hitch is suitable for all our drives from the Earth Drill X1500 to the Earth Drill 50,000MAX. The use of a Cradle hitch is recommended by Auger Torque as it will eliminate Auger swing during dirt shake off, will enable you to safely transport your Earth Drill and Auger on site and will also help you in lining up your holes with precision. No mechanical parts or dampers mean that even if your Earth Drill and hitch have a tough life ahead of them you will not have to worry about costly replacements or breakdowns.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style hitch. When ordering this hitch please supply your pin diameter, dipper width and distance between pin centres.
Augertorque Double Pin Cradle Hitch available for Earth Drills 3000Max TO 4500Max in various Pin diameters (30mm, 32mm, 35mm, 38mm, 40mm, 44mm (1.3 / 4″), 45mm, 50mm, 55mm, 60mm).
| 25mm DOUBLE PIN CRADLE HITCH – 3000Max TO 4500Max |
| 30mm DOUBLE PIN CRADLE HITCH – 3000Max TO 4500Max |
| 32mm DOUBLE PIN CRADLE HITCH – 3000Max TO 4500Max |
| 35mm DOUBLE PIN CRADLE HITCH – 3000Max TO 4500Max |
| 40mm DOUBLE PIN CRADLE HITCH – 3000Max TO 4500Max
44mm (1.3/4″) DOUBLE PIN CRADLE HITCH – 3000MAX TO 4500MAX |
The Double Pin Cradle Earth Drill hitch can be supplied in both loose and fixed pin versions to suit standard and quick hitch solutions on most excavators & backhoes. This hitch is suitable for all our drives from the Earth Drill X1500 to the Earth Drill 50,000MAX. The use of a Cradle hitch is recommended by Auger Torque as it will eliminate Auger swing during dirt shake off, will enable you to safely transport your Earth Drill and Auger on site and will also help you in lining up your holes with precision. No mechanical parts or dampers mean that even if your Earth Drill and hitch have a tough life ahead of them you will not have to worry about costly replacements or breakdowns.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style hitch. When ordering this hitch please supply your pin diameter, dipper width and distance between pin centres.
| 25mm DOUBLE PIN CRADLE HITCH – X2000 TO X2500 |
| 30mm DOUBLE PIN CRADLE HITCH – X2000 TO X2500 |
| 32mm DOUBLE PIN CRADLE HITCH – X2000 TO X2500 |
| 35mm DOUBLE PIN CRADLE HITCH – X2000 TO X2500 |
| 40mm DOUBLE PIN CRADLE HITCH – X2000 TO X2500 |
The Double Pin Cradle Earth Drill hitch can be supplied in both loose and fixed pin versions to suit standard and quick hitch solutions on most excavators & backhoes. This hitch is suitable for all our drives from the Earth Drill X1500 to the Earth Drill 50,000MAX. The use of a Cradle hitch is recommended by Auger Torque as it will eliminate Auger swing during dirt shake off, will enable you to safely transport your Earth Drill and Auger on site and will also help you in lining up your holes with precision. No mechanical parts or dampers mean that even if your Earth Drill and hitch have a tough life ahead of them you will not have to worry about costly replacements or breakdowns.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style hitch. When ordering this hitch please supply your pin diameter, dipper width and distance between pin centres.
| 44mm (1.3/4″) DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 45mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 50mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 55mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 60mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 65mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 70mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 75mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
| 80mm DOUBLE PIN HITCH – 10,000 TO 25,000MAX |
Description
The Double Pin Earth Drill hitch can be supplied in both loose and fixed pin versions to suit standard and quick hitch solutions on most excavators & backhoes. This hitch is suitable for all our drives from the 10000MAX and 25000MAX Earth Drills. Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style hitch.
When ordering this hitch please supply your pin diameter, dipper width and distance between pin centres.
| 30mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 32mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 35mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 40mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 44mm (1.3/4″) DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 45mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 50mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 55mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 60mm DOUBLE PIN HITCH – 3000MAX TO 4500MAX |
| 40mm DOUBLE PIN HITCH – 5000 TO 8000MAX |
| 44mm (1.3/4″) DOUBLE PIN HITCH – 5000 TO 8000MAX |
| 45mm DOUBLE PIN HITCH – 5000 TO 8000MAX |
| 50mm DOUBLE PIN HITCH – 5000 TO 8000MAX |
| 55mm DOUBLE PIN HITCH – 5000 TO 8000MAX |
| 60mm DOUBLE PIN HITCH – 5000 TO 8000MAX |
| 65mm DOUBLE PIN HITCH – 5000 TO 8000MAX |
The Double Pin Earth Drill hitch can be supplied in both loose and fixed pin versions to suit standard and quick hitch solutions on most excavators & backhoes. This hitch is suitable for all our drives from the 7000MAX and 8000MAX Earth Drills. Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style hitch.
When ordering this hitch please supply your pin diameter, dipper width and distance between pin centres.
| 25mm DOUBLE PIN HITCH – X2000 TO X2500 |
| 30mm DOUBLE PIN HITCH – X2000 TO X2500 |
| 32mm DOUBLE PIN HITCH – X2000 TO X2500 |
| 35mm DOUBLE PIN HITCH – X2000 TO X2500 |
| 40mm DOUBLE PIN HITCH – X2000 TO X2500 |
The Double Pin Earth Drill hitch can be supplied in both loose and fixed pin versions to suit standard and quick hitch solutions on most excavators & backhoes. This hitch is suitable for all our drives from the Earth Drill 1200 to the Earth Drill 25,000MAX.
| 1.3/4″ SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 45mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 50mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 55mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 60mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 65mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 70mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 75mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
| 80mm SINGLE PIN HITCH (45) – 10000 TO 25000MAX |
The Single Pin Earth Drill hitch is the most basic and most low cost hitch option Auger Torque offers and is suitable for excavators and backhoes. Available for all drives in our range from the Earth Drill 1200 all the way to the Earth Drill 50,000MAX.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style of hitch. When ordering this hitch please supply your pin diameter and dipper width or request our hitch specification form. Not compatible with hydraulic quick hitches, select a double pin hitch or double pin cradle hitch with your Earth Drill package instead.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style of hitch. When ordering this hitch please supply your pin diameter and dipper width or request our hitch specification form. Not compatible with hydraulic quick hitches, select a double pin hitch or double pin cradle hitch with your Earth Drill package instead.The Single Pin Earth Drill hitch is the most basic and most low cost hitch option Auger Torque offers and is suitable for excavators and backhoes. Available for all drives in our range from the Earth Drill 1200 all the way to the Earth Drill 50,000MAX.
| 40mm SINGLE PIN HITCH – 5000 TO 8000MAX |
| 44.5mm / 1.3/4″ SINGLE PIN HITCH – 5000 TO 8000MAX |
| 45mm SINGLE PIN HITCH – 5000 TO 8000MAX |
| 50mm SINGLE PIN HITCH – 5000 TO 8000MAX |
| 55mm SINGLE PIN HITCH – 5000 TO 8000MAX |
| 60mm SINGLE PIN HITCH – 5000 TO 8000MAX |
The Single Pin Earth Drill hitch is the most basic and most low cost hitch option Auger Torque offers and is suitable for excavators and backhoes. Available for all drives in our range from the Earth Drill 1200 all the way to the Earth Drill 50,000MAX.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style of hitch. When ordering this hitch please supply your pin diameter and dipper width or request our hitch specification form. Not compatible with hydraulic quick hitches, select a double pin hitch or double pin cradle hitch with your Earth Drill package instead.
| 25mm SINGLE PIN HITCH – X1500 TO 4500MAX |
| 30mm / 1.3/4″ SINGLE PIN HITCH – X1500 TO 4500MAX |
| 32mm SINGLE PIN HITCH – X1500 TO 4500MAX |
| 35mm SINGLE PIN HITCH – X1500 TO 4500MAX |
| 38mm SINGLE PIN HITCH – X1500 TO 4500MAX |
| 40mm SINGLE PIN HITCH – X1500 TO 4500MAX |
The Single Pin Earth Drill hitch is the most basic and most low cost hitch option Auger Torque offers and is suitable for excavators and backhoes. Available for all drives in our range from the Earth Drill 1200 all the way to the Earth Drill 50,000MAX.
Just like all Auger Torque products only the highest grade steel is used in the fabrication of this style of hitch. When ordering this hitch please supply your pin diameter and dipper width or request our hitch specification form. Not compatible with hydraulic quick hitches, select a double pin hitch or double pin cradle hitch with your Earth Drill package instead.
